DonoBrace Spec Guide 206x260

Technical Information

This booklet includes information on testing, installation, design/dimensions and guidance for structural engineers.

Download DonoBrace® Specification and Installation Guide (NZ) Tech FAQs

Why DonoBrace®?

SIMPLE TO SPECIFY & DESIGN

The design, engineering and specification process is simple with DonoBrace®.

Structural engineers simply select and place the specific sized DonoBrace® component into structural drawings using compatible drafting software.

MORE CAPACITY AND LESS WEIGHT

The DonoBrace® G830 threaded galvanised bar has been tested to AS/NZ 1170.0 with G350 plate connections. This higher capacity result means you can choose a smaller diameter and lighter weight bar than competitor products.

FAST TO INSTALL

DonoBrace® is designed for simple and efficient installation. The steel bracing product ends allow for less sophisticated coupling components, dramatically decreasing installation time.

SUPERIOR QUALITY & DYNAMICALLY TESTED

DonoBrace® is dynamically tested for Seismic Activity, along with for Hydrogen Embrittlement.

DonoBrace® is manufactured with machined nuts and bolts for reliability. All Endplates are plasma cut, induction heated and pressed for performance.

TRANSPARENT ONSITE INSPECTIONS

Each coupler comes standard with two inspection holes for quick and simple verification that both rods are fully engaged.

STANDARDISED STOCK COMPONENTS

From the machined nuts and washers to the couplers, high tensile rod, and end plates, all parts are standardised for project flexibility.

Donobrace 5 1024x684
DonoBrace 1 1024x684
DonoBrace 2 1024x684
DonoBrace 3 1024x684
DonoBrace 4 1024x684
DonoBrace Roma 014 1024x681
DonoBrace Roma 003 1024x681
DonoBrace Roma 028 1024x681



Tried & Tested

At DonoBrace® we pride ourselves on our superior performance and comprehensive testing. To ensure the correct calculated capacities are achieved, it is imperative that DonoBrace® is used as a completed supplied system. No material substitutions are to be made without specific written authority.

Installation Video

Dynamic Testing Video

 We at Grayson Engineering (2015) Limited, are a regular user of the DonoBrace® system and we are thoroughly pleased with the product. It is readily available, easy and efficient to install, and the local support team is excellent.

David Moore - Managing Director
Progress_072-scaled-1-1024x684

DONOBRACE KEY PROJECT:

Ha Crescent, Auckland

Length: 187m

Width: 59.4m

Knee Height: 13m

Floor Area: 10,850m²

Building Use: Commercial and Industrial

Portal System: DonoBeam



Design and Detailing Files

DB15EC

SAT file
IFC file

DB20EC

SAT file
IFC file

DB25EC

SAT file
IFC file

Other downloads

Revit MP4 file
RFA – DonoBrace file
Tekla link
